1. Technical Specifications
Number of Pairs: 4 pairs (8 strands)
Conductor Type: CCAM (Copper-Clad Aluminum), 60/0 stranded (60 fine strands)
Conductor Cross-Section: Approx. 0.6 mm²
Pair Insulation: Polyethylene (PE), each pair color-coded
Shield: Aluminum-polyester foil with 100% coverage, copper drain wire for grounding
Outer Jacket: UV-resistant PVC, suitable for harsh environmental conditions
Operating Voltage: Up to 200 V
Operating Temperature: -20°C to +60°C
Standards Compliance: TCI, VDE 0815, ASTM D 4565
2. Applications
Subscriber Connections: Ideal for ground telephone lines between central offices and subscribers
Signal Transmission: Suitable for voice and data transmission (e.g., ADSL) in urban and rural environments
Ground Installation: Designed for direct burial or installation in underground ducts
3. Protective Features
EMI Reduction: Foil shielding and copper drain wire minimize noise and signal interference
Signal Stability: Foil-shielded structure improves signal quality and stability over ground installations
4. Installation and Maintenance
Installation Method: Direct burial in soil or placement within underground ducts
Shield Connection: Connect drain wire to the grounding system at a single point to prevent ground loops
Maintenance: Periodic inspection of outer jacket and shield ensures optimal performance
5. Packaging and Dimensions
Coil Length: 250 m or 500 m (customizable)
Approx. Weight: ~120 kg per 500 m coil
Packaging: Robust packaging for safe and easy transport
6. Comparison with Similar Products
Versus Non-Shielded Cables: The foil-shielded Noan-A4CCAM provides superior protection against noise and interference
Versus Pure Copper Cables: Using CCAM conductors, the cable is lighter and more cost-effective while maintaining reliable performance
7. Conclusion
The Noan-A4CCAM cable, with foil shielding and CCAM conductors, is an excellent choice for terrestrial telecommunications signal transmission. It combines protective features, easy installation, and cost efficiency, making it ideal for a wide range of ground telecom projects.
